This wouldn't be it??? http://www.diyaudio.com/forums/showthread.php?postid=941943#post941943
I read the article too Stuart.
Aside from the usual compliments for the great work, I would like to know more about the issue of overload recovery.
A simple question for now: what do you think of driving a power tube (not extreme ones) in a PP with a cathode follower, dc coupled? Are there really advantages in DC coupling (assuming that I don't need necessary A2 drive)?
And if I drive power tubes with a cathode follower, would be cathode bias an option or would you consider only fixed bias? Leds are not applicable here because I would need an insane amount of them
Thank you very much.
Aside from the usual compliments for the great work, I would like to know more about the issue of overload recovery.
A simple question for now: what do you think of driving a power tube (not extreme ones) in a PP with a cathode follower, dc coupled? Are there really advantages in DC coupling (assuming that I don't need necessary A2 drive)?
And if I drive power tubes with a cathode follower, would be cathode bias an option or would you consider only fixed bias? Leds are not applicable here because I would need an insane amount of them
![xeye :xeye: :xeye:](https://files.diyaudio.com/forums/images/smilies/xeye.gif)
Thank you very much.
Walt, it needs some green LEDs for that use!
The CF is an optimal way to do it. Even if you don't push the output into grid current, you extend bandwidth and (if the CF is direct coupled) prevent blocking. It also allows triode operation. If cost and complexity are no object, that's the way I'd go.
what do you think of driving a power tube (not extreme ones) in a PP with a cathode follower, dc coupled? Are there really advantages in DC coupling (assuming that I don't need necessary A2 drive)?
The CF is an optimal way to do it. Even if you don't push the output into grid current, you extend bandwidth and (if the CF is direct coupled) prevent blocking. It also allows triode operation. If cost and complexity are no object, that's the way I'd go.
Hi SY,
The article was good reading.
The Christmas version has some green pilot lights around the power switch. It flashes during warm-up like a Counterpoint!![devil_r :devilr: :devilr:](https://files.diyaudio.com/forums/images/smilies/devil.gif)
-Chris
My apologies to you. Your MJE340 in the high voltage section is pointing the correct way. I just looked at the diagram too quickly and expected the raw power feed from the right.
The article was good reading.
The Christmas version has some green pilot lights around the power switch. It flashes during warm-up like a Counterpoint!
![devil_r :devilr: :devilr:](https://files.diyaudio.com/forums/images/smilies/devil.gif)
-Chris
SY said:I coulda sworn it was a TIP 50...
TIP 50
Attachments
SY said:The complete article on this amp has now appeared in Bas Horneman's diy magazine:
Compromised URL removed by Moderation
Wow, thats a very impressive article.
Congrats Sy on a truely outstanding project!!
Now, somebody please PM me and explain the redlight symbols meaning? lol
Trout
Last edited by a moderator:
