I would be in for this if the 4" was this: 4NDF34 LF Drivers - B&C Speakers
Yes....that would be very nice indeed. I thought about suggesting a co-entrant version as well but figured it's a hard sell for a small operation.
Sure -Marcel, can you show what a 10° exit on a 10° mouth does in your simulation? Just out of interest.
Attachments
As for the injection molded waveguides, I would like to make it from clear (UV stable) plastic. Probably as a two-part product to keep the mold simple, with a separate aluminum mounting flange. Should not the transparent look be preferred, painted from the back side it could make a high-gloss quality finish with minimum effort.
I'm going to start a crowdfunding project soon, somewhere.
I'm going to start a crowdfunding project soon, somewhere.
Last edited:
I can still order the epoxy-coated sand prints, or make something of the CE series using this technology, but only locally (i.e. Czechia) as the shipping is quite a hassle - it's heavy and too brittle, I'm afraid. Too much work to pack it properly, not something I would be eager to do again.
If somebody living around here were willing to do it, I have no problem ordering these directly to him/her to ship it further.
Measured SPL data: #7402
If somebody living around here were willing to do it, I have no problem ordering these directly to him/her to ship it further.
Measured SPL data: #7402
Attachments
Last edited:
Products | MODELARNA LIAZ
Products | MODELARNA LIAZ
Last edited:
Probably it could be casted as two (thinner) aluminum pieces, put together as constrained layer damped (?).
This would be ideal, but probably quite expensive. Once I had the mold, casting with polyurethane cost only about $50/each. These had between 1" and 4" of wall thickness (1" at mouth, 4" at mounting,) and with the glass fill were extremely dead.
I'm quite reluctant to buy an expensive mold to produce the waveguides manually by myself, that's something I don't feel like doing at the moment, honestly. So I just think about how to let it made in high enough quality so it wouldn't cost a fortune. There are really not many options I guess.
- Regarding vibrations and damping, I wonder how is the situation different when free standing (attached to a driver stand via the narrow end) compared to when mounted in a box, which can vibrate by itself in quite a complicated pattern. Is it supposed to be more critical or less critical when free standing?
- Regarding vibrations and damping, I wonder how is the situation different when free standing (attached to a driver stand via the narrow end) compared to when mounted in a box, which can vibrate by itself in quite a complicated pattern. Is it supposed to be more critical or less critical when free standing?
As far as I know they are quite happyI'm a bit surprised there haven't been that many reports form the sand horn receivers. Maybe it was only to you - are they happy?
//
More on this, what's actually the biggest source of mechanical vibrations and resonances in waveguides? I would think the vibrations from a compression driver itself are miniscule, not something to worry about. So is it the bass driver, causing vibrations on the surrounding objects? Is it then possible to isolate a free standing waveguide by a damped (or completely separated) mounting? This would by my intuition. Or is it the sound itself? Wouldn't be aluminum alone satisfactory, if heavy enough?- Regarding vibrations and damping, ...
Last edited:
As to the actual level of the vibrations in a waveguide itself, I don't have a feeling for how critical it is, so I just made them dead as that can never be the wrong thing to do.
Free standing will have lower resonances than in a box. It's like a cantilever and those are always lower frequency resonances than a clamped beam. How much of a difference this makes is unknown. Even free standing, I would clamp the mouth to something and damp the mounts on both ends.
Free standing will have lower resonances than in a box. It's like a cantilever and those are always lower frequency resonances than a clamped beam. How much of a difference this makes is unknown. Even free standing, I would clamp the mouth to something and damp the mounts on both ends.
Last edited:
